A dome defense system engineered for counter strike FPV drones within the 700–1020 MHz radio frequency range.
[0.1] Key Specifications
700 - 1020 MHz
360
0
The system is designed to protect both stationary and mobile assets.
Contact us for a consultation
[0.2] Scope of Application
Light vehicles (ATVs, buggies, etc.)
[0.3] System Components
The system consists of two functional units that operate together as a single entity, but can function independently if required.
[0.4] Detailed Specifications
Operating frequency range
700 – 1020
MHz
Number of RF channels
2
units
RF jamming bandwidth
320
MHz
Right-hand circular polarization (RHCP)
Left-hand circular polarization (LHCP)
Voltage Standing Wave Ratio (VSWR)
1,7
Output power
Effective jamming range
100–300 m
Targeted protocols
ExpressLRS, TBS Crossfire, and modifications
Reliability rating (MTBF)
800
hours
Crew required
2 personnel
Cooling System
Cooling system type
Active cooling
Number of fans per unit
2 (pcs)
Fan speed range
500 - 10000 (rpm)
Airflow
174 (m³/h)
/
102 CFM
Environmental Specifications
Ingress Protection rating
IP56
Operating temperature range
-20 ~ +50 (°C)
Atmospheric pressure
760 (mmHg)
Precipitation resistance
Max operational wind speed
30 (m/s)
Vehicle power system
Continuous (with vehicle engine running)
External battery (24V, 200Ah)
Minimum recommended battery specifications
Power Supply System
Power supply type
External (via 24V 80Ah external battery and/or generator)
Operating voltage
12-36 (V)
Current consumption
45 А (at 12V voltage)
Installation & Connection
Installation time on an unarmored vehicle
270 (min)
Installation time on a light armored vehicle (LAV)
360 (min)
Connection time for stationary installation
90 (min)
System power-on / power-off time
10 (s)
Weight
System weight in transit packaging
44±0.5 (kg)
Including mounting system
Unit 1
10(kg)
Unit 2
10(kg)
Physical dimensions
990±10/450±10/460±10 (mm)
Including mounting system
Unit 1
Unit 2
